Our white food-grade solid woven conveyor belt is designed for hygiene-critical applications across food processing industries. With a seamless construction, it eliminates fraying and ensures exceptional durability, even under heavy loads. This belt is resistant to moisture, oils, and chemicals, making it ideal for bakeries, meat processing, and dairy production. Its smooth, easy-to-clean surface meets stringent food safety standards, ensuring contamination-free operations. Built for reliable performance, it supports efficient material handling in demanding environments while maintaining strict hygiene.
Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.
| TYPE # | |
| SOLID150/0.1+2.0/5.0W | |
| REFERENCE # | |
| GENERAL CHARACTERISTICS: | |
| SUITABLE FOR MOST OF LINES AND PRODUCTS | |
| GENERAL TRANSPORT | |
| TECHNICAL CHARACTERISTICS : | |
| Total Thickness | 5.0 mm |
| No. of Plies | 1 |
| Fabric | Interwoven |
| Weft | Flexible |
| Weight | 5.5 kg(s)/㎡ |
| Working Temperatures | -15 ºC to + 70 ºC |
| 1. Top cover | |
| Thickness | 2.0mm |
| Material | PVC |
| Color | White (W) |
| Surface | Glossy |
| Hardness | 75 ShA |
| 2. Internal layer(s) | |
| Material | - |
| Color | - |
| 3. Bottom cover | |
| Thickness | 0.1mm |
| Material | PVC |
| Color | White (W) |
| Surface | Impregnation |
| Hardness | - |
| Anti-static Yarn | - |
| BELT TENSION: | |
| Tensile Strength(N/mm) | 150 |
| Max. Suggested Load(N/mm) | 22 |
| Working Load 2% Elongation(N/mm) | 24 |
| FRICTION COEFFICIENTS ON: | |
| Smooth Stainless Steel | 0.42 |
| REMARKS | |
| Max. Manufacturing Width | 3000mm |
| Standard Width | 2000mm, 3000mm |
| MINIMUM PULLEY DIAMETERS: | |
| Front Flexing | 100 mm |
| Back Flexing | 120 mm |
| CONVEYOR FRAME: | |
| Horizontal Rollers | Yes |
| Slider bed | Yes |
| Troughed application | Yes |
| SPECIAL CHARACTERISTICS: | |
| Food Grade | Yes |
| Oil Resistant | No |
| Flame Retardant | No |
| Surface Antistatic | No |
| Cold Resistant | No |
| JOINING INSTRUCTIONS: | |
| Finger Joint | Fastener |
| Welding Temperature（°C） | 175 °C ± 10 °C |
| Pressure | 2 bar |
| Cooling | Cool Immediately |
