Homogeneous conveyor belt specially designed to meet the highest food safety standards, and ensures a hygienic and reliable transportation method for various food products throughout the processing line.
Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.
#KCB-AT40 Homogeneous Conveyor Belt For Food Processing
Structure Diagram:

| Type | KCB-AT40 | KCB-AT40 |
|---|---|---|
| Standard Width (mm) | 1200 | 1200 |
| Color | Dark Blue | Sky Blue |
| Material Of Surface | Polyether PU | Polyester PU |
| Structure Of Surface | Glossy | |
| Structure Of Bottom | Rounded Tooth | |
| Pitch Between Teeth(mm) | 40.0 | |
| Length Of Teeth (mm) | 69 | |
| Material Of Strength Layer | Aramid Fiber | |
| Total Thickness (mm) | 11.0 | |
| Thickness Of Base (mm) | 3.0 | |
| Height of Teeth (mm) | 8.0 | |
| Length of Teeth (mm) | 75 | |
| Pitch Between Teeth (mm) | 40 | |
| Weight (kg/㎡) | 7.0 | |
| 1% Elongation (N/mm) | 16 | |
| Roller Diameter In Minimum (23℃) mm | 120 | |
| Coefficient Of Friction (Steel Plate) | 0.6 (wet) / 0.4 (dry) | |
| Coeficient Of Friction (UHMWPE) | 0.15 | |
| Working Temperature ℃ | -30/+60 | -5/+80 |
| Hardness Of Surface (Sh A) | 95 | 95 |
| Stability Of Weft | √ | √ |
| Acid And Alkali Resistant | √ | √ |
| Oil Resistant | √ | √ |
| Food Grade | √ | √ |
| Low Temperature Resistant | ||
| Metal Detecting | ||
| Hydrolysis Resistant | √ | |
| Level Of Mildew Resistant* | 0 | 1 |
| Salt Resistant | √ | √ |
| Optional Pulley | ||
| Remarks: Mildew grade 0: Mildew grade 1: |
No mold growth under the test conditions specified by ISO. Mild growth of mold under ISO test conditions. |
|
