Featuring high conductivity, high lateral stability, and excellent release property, our Cross-Lapper Belt/Nonwoven Conveyor Belt meets all the rigorous demands of modern Cross-lapper/web-laying machines in the non-woven fabric industry.
With highly conductive coating and low friction surface with high-grade TPU material, this nonwoven conveyor belt ensures even, continuous webbing and piling of non-woven fabrics, enabling high-speed processing and excellent release properties for fiber webs, and delivering trouble-free conveying and high-speed, precise processing, while maintaining long service life.
Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.
| TYPE # | |
| EM100/2:0.1+0.2M/1.1BPU/HC | |
| REFERENCE # | |
| E 4/2 U0/U2 LF-HC+ | |
|
ENB-6EE ENB-9EE |
|
| GENERAL CHARACTERISTICS: | |
| SUITABLE FOR HIGH-SPEED SYSTEMS AND FOR | |
| NON-WOVEN CONVEYOR BELT/CROSS-LAPPER BELT | |
| HIGHLY CONDUCTIVE | |
| TECHNICAL CHARACTERISTICS : | |
| Total Thickness | 1.1 mm |
| No. of Plies | 2 |
| Fabric | Polyester(EM) |
| Weft | Rigid |
| Weight | 1.2 kg(s)/㎡ |
| Working Temperatures | -10 ºC to + 70 ºC |
| 1. Top cover | |
| Thickness | 0.2 mm |
| Material | TPU |
| Color | Black (B) |
| Surface | Matt |
| Hardness | 85 ShA |
| High Conductive | Yes |
| 2. Internal layer(s) | |
| Material | TPU |
| Color | Black (B) |
| 3. Bottom cover | |
| Thickness | 0.1 mm |
| Material | TPU |
| Color | Black (B) |
| Surface | Fabric with Immpregnation |
| Hardness | - |
| Anti-static Yarn | Yes |
| BELT TENSION: | |
| Tensile Strength(N/mm) | 100 |
| Max. Suggested Load(N/mm) | 4 |
| Working Load 1% Elongation(N/mm) | 6 |
| FRICTION COEFFICIENTS ON: | |
| Smooth Stainless Steel | 0.17 |
| REMARKS | |
| Max. Manufacturing Width | 4000mm |
| Standard Width | 2000mm, 3000mm |
| MINIMUM PULLEY DIAMETERS: | |
| Front Flexing | 50 mm |
| Back Flexing | 50 mm |
| CONVEYOR FRAME: | |
| Horizontal Rollers | Yes |
| Slider bed | Yes |
| Troughed application | No |
| SPECIAL CHARACTERISTICS: | |
| Food Grade | Yes |
| Oil Resistant | Yes |
| Flame Resistant | No |
| Surface Antistatic | Yes, 3*108 |
| Cold Resistant | No |
| High Conductive | Yes |
| JOINING INSTRUCTIONS: | |
| Finger Joint | Yes |
| Welding Temperature（°C） | 165 °C ± 10 °C |
| Pressure | 2 bar |
| Cooling | Cool Immediately |
