Specially designed for stone processing applications, providing outstanding performance in harsh, heavy-duty environments. With a robust construction and high tensile strength, this belt is built to handle abrasive and demanding materials efficiently.
Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.
| TYPE # | |
| AEF900/3:0+3.0RD/10.0B | |
| REFERENCE # | |
| GENERAL CHARACTERISTICS: | |
| SUITABLE FOR MOST OF LINES AND PRODUCTS | |
| GENERAL TRANSPORT | |
| HEAVY DUTY | |
| ESPECIALLY FOR STONE PROCESSING | |
| TECHNICAL CHARACTERISTICS : | |
| Total Thickness | 10.0 mm |
| No. of Plies | 3 |
| Fabric | Polyester(AEF) |
| Weft | Flexible |
| Weight | 11.5 kg(s)/㎡ |
| Working Temperatures | -10 ºC to + 70 ºC |
| 1. Top cover | |
| Thickness | 3.0 mm |
| Material | PVC |
| Color | Black (B) |
| Surface | Small Nipple (RD) |
| Hardness | 80 ShA |
| 2. Internal layer(s) | |
| Material | PVC |
| Color | Black (B) |
| 3. Bottom cover | |
| Thickness | - |
| Material | - |
| Color | Black (B) |
| Surface | Fabric with Impregnation |
| Hardness | - |
| Anti-static Yarn | - |
| BELT TENSION: | |
| Tensile Strength(N/mm) | 900 |
| Max. Suggested Load(N/mm) | 50 |
| Working Load 1% Elongation(N/mm) | 60 |
| FRICTION COEFFICIENTS ON: | |
| Smooth Stainless Steel | 0.35 |
| REMARKS | |
| Max. Manufacturing Width | 2200mm |
| Standard Width | 2000mm |
| MINIMUM PULLEY DIAMETERS: | |
| Front Flexing | 450 mm |
| Back Flexing | 500 mm |
| CONVEYOR FRAME: | |
| Horizontal Rollers | Yes |
| Slider bed | Yes |
| Troughed application | Yes |
| SPECIAL CHARACTERISTICS: | |
| Food Grade | No |
| Oil Resistant | No |
| Flame Retardant | No |
| Surface Antistatic | No |
| Cold Resistant | No |
| JOINING INSTRUCTIONS: | |
| Finger Joint | Step Joint |
| Welding Temperature（°C） | 175 °C ± 10 °C |
| Pressure | 2 bar |
| Cooling | Cool Immediately |
