High Load Capacity, Durable PVC Belt for Stone Processing #AEF1200/4:0+2.5TR/9.0SB
High Load Capacity, Durable PVC Belt for Stone Processing #AEF1200/4:0+2.5TR/9.0SB
High Load Capacity, Durable PVC Belt for Stone Processing #AEF1200/4:0+2.5TR/9.0SB
High Load Capacity, Durable PVC Belt for Stone Processing #AEF1200/4:0+2.5TR/9.0SB
High Load Capacity, Durable PVC Belt for Stone Processing #AEF1200/4:0+2.5TR/9.0SB
High Load Capacity, Durable PVC Belt for Stone Processing #AEF1200/4:0+2.5TR/9.0SB

High Load Capacity, Durable PVC Belt for Stone Processing #AEF1200/4:0+2.5TR/9.0SB

With its high load-bearing capacity, robust construction, and low maintenance requirements, this PVC conveyor belt is the ideal solution for industries requiring heavy-duty, long-lasting, and reliable conveyor systems. Perfect for conveying stones, marbles, etc…

  • High Load Capacity: Built with high tensile strength to handle heavy and bulk materials, ensuring seamless transport even under high load conditions.
  • Durability and Robustness: Manufactured with superior-quality PVC, this belt offers excellent abrasion resistance, making it ideal for harsh environments where long-lasting performance is critical.
  • Low Maintenance: The durable design of the AEF1200/4:0+2.5TR/9.0SB minimizes wear and tear, reducing downtime and maintenance costs.

Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.

Specification
TYPE #
AEF1200/4:0+2.5TR/9.0SB
REFERENCE #

GENERAL CHARACTERISTICS:
SUITABLE FOR MOST OF LINES AND PRODUCTS
GENERAL TRANSPORT
HEAVY DUTY
ESPECIALLY FOR STONE PROCESSING
TECHNICAL CHARACTERISTICS :
Total Thickness 9.0 mm
No. of Plies 4
Fabric Polyester(AEF)
Weft Flexible
Weight 10.5 kg(s)/㎡
Working Temperatures -10 ºC to + 70 ºC
1. Top cover 　
Thickness 2.5 mm
Material PVC
Color Sky Blue (SB)
Surface Triangle (TR)
Hardness 80 ShA
2. Internal layer(s)
Material PVC
Color Sky Blue (SB)
3. Bottom cover 　
Thickness -
Material -
Color Sky Blue (SB)
Surface Fabric with Impregnation
Hardness -
Anti-static Yarn -
BELT TENSION:
Tensile Strength(N/mm) 1200
Max. Suggested Load(N/mm) 70
Working Load 1% Elongation(N/mm) 80


FRICTION COEFFICIENTS ON: 　
Smooth Stainless Steel 0.35

REMARKS 　
Max. Manufacturing Width  2200mm
Standard Width 2000mm
MINIMUM PULLEY DIAMETERS:
Front Flexing 450 mm
Back Flexing 500 mm

CONVEYOR FRAME:
Horizontal Rollers Yes
Slider bed Yes
Troughed application Yes




SPECIAL CHARACTERISTICS:
Food Grade No
Oil Resistant No
Flame Retardant No
Surface Antistatic No
Cold Resistant No
JOINING INSTRUCTIONS:
Finger Joint Step Joint
Welding Temperature（°C） 175 °C ± 10 °C
Pressure 2 bar
Cooling Cool Immediately
