| TYPE # | |
| EM120/2:0.5DT+0.8/3.0W | |
| REFERENCE # | |
| GENERAL CHARACTERISTICS: | |
| SUITABLE FOR MOST OF PRODUCTION LINES | |
| GENERAL TRANSPORT | |
| TECHNICAL CHARACTERISTICS : | |
| Total Thickness | 3.0 mm |
| No. of Plies | 2 |
| Fabric | Polyester |
| Weft | Rigid |
| Weight | 3.6 kg(s)/㎡ |
| Working Temperatures | -10 ºC to + 70 ºC |
| 1. Top cover | |
| Thickness | 0.8 mm |
| Material | PVC |
| Color | White (W) |
| Surface | Glossy |
| Hardness | 75 ShA |
| 2. Internal layer(s) | |
| Material | PVC |
| Color | White (W) |
| Fabric | |
| 3. Bottom cover | 0.5mm |
| Thickness | PVC |
| Material | White (W) |
| Color | Diamond (DT) |
| Surface | 80 ShA |
| Hardness | - |
| Anti-static Yarn | |
| BELT TENSION: | |
| Tensile Strength(N/mm) | 120 |
| Max. Suggested Load(N/mm) | 8 |
| Working Load 1% Elongation(N/mm) | 10 |
| FRICTION COEFFICIENTS ON: | |
| Smooth Stainless Steel | 0.35 |
| REMARKS | |
| Max. Manufacturing Width | 4000mm |
| Standard Width | 2000mm, 3000mm |
|
TOP BOTTOM |
|
| MINIMUM PULLEY DIAMETERS: | |
| Front Flexing | 60 mm |
| Back Flexing | 60 mm |
| CONVEYOR FRAME: | |
| Horizontal Rollers | Yes |
| Slider Bed | Yes |
| Troughed Application | No |
| SPECIAL CHARACTERISTICS: | |
| Food Grade | Yes |
| Oil Resistant | No |
| Flame Retardant | No |
| Surface Antistatic | No |
| Cold Resistant | No |
| JOINING INSTRUCTIONS: | |
| Finger Joint | Yes |
| Welding Temperature（ºC） | 175 ºC ± 10 ºC |
| Pressure | 2 bar |
| Cooling | Cool immediately |
