ECM fabric construction provides a balance of flexibility and stability, while the bareback surface ensures reliable grip without adhesion. The belt performs reliably under continuous operation,
supporting precise material flow and long service life.
Key Features
Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.
| TYPE # | |
| ECM300/3:0+0/4.0W | |
| REFERENCE # | |
| GENERAL CHARACTERISTICS: | |
| SUITABLE FOR MOST OF LINES AND PRODUCTS | |
| HEAVY DUTY | |
| TEA PROCESSING | |
| TIRE PRODUCTION | |
| TECHNICAL CHARACTERISTICS : | |
| Total Thickness | 4.0 mm |
| No. of Plies | 3 |
| Fabric | Polyester + Cotton |
| Weft | Rigid |
| Weight | 4.8 kg(s)/㎡ |
| Working Temperatures | -10 ºC to + 80 ºC |
| 1. Top cover | |
| Thickness | - |
| Material | - |
| Color | Natural |
| Surface | Bare Fabric |
| Hardness | - |
| 2. Internal layer(s) | |
| Material | PVC |
| Color | White(W) |
| 3. Bottom cover | |
| Thickness | - |
| Material | - |
| Color | Natural |
| Surface | Bare Fabric |
| Hardness | - |
| Anti-static Yarn | - |
| BELT TENSION: | |
| Tensile Strength(N/mm) | 300 |
| Max. Suggested Load(N/mm) | 12 |
| Working Load 1% Elongation(N/mm) | 14 |
| FRICTION COEFFICIENTS ON: | |
| Smooth Stainless Steel | 0.18 |
| REMARKS | |
| Max. Manufacturing Width | 4000mm |
| Standard Width | 2000mm, 3000mm |
| MINIMUM PULLEY DIAMETERS: | |
| Front Flexing | 80 mm |
| Back Flexing | 100 mm |
| CONVEYOR FRAME: | |
| Horizontal Rollers | Yes |
| Slider bed | Yes |
| Troughed application | No |
| SPECIAL CHARACTERISTICS: | |
| Food Grade | Yes |
| Oil Resistant | No |
| Flame Retardant | No |
| Surface Antistatic | No |
| Cold Resistant | No |
| High Temperature | No |
| JOINING INSTRUCTIONS: | |
| Finger Joint | Step Joint |
| Welding Temperature（°C） | 175 ºC ± 10 ºC |
| Pressure | 2 bar |
| Cooling | Cool Immediately |
