This silicone coated rubber conveyor belt is designed for reliable handling of hot, sticky rubber compounds in demanding industrial environments. The silicone surface provides superior release properties, preventing material buildup and ensuring clean, consistent conveying. Engineered for high temperatures and continuous operation, this belt supports stable performance across key rubber and tire manufacturing processes.
Folded-edge version available.
Key Features
Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.
| TYPE # | |
| EC+EP400/4:0+0.1SI/5.0R/RUB | |
| REFERENCE # | |
| GENERAL CHARACTERISTICS: | |
| GENERAL TRANSPORT | |
| ESPECIALLY FOR TIRE INDUSTRY | |
| TECHNICAL CHARACTERISTICS : | |
| Total Thickness | 5.0 mm |
| No. of Plies | 4 |
| Fabric | Polyester (EC + EP) |
| Weft | Flexible |
| Weight | 6.0 kg(s)/㎡ |
| Working Temperatures | -30 ºC to + 160 ºC |
| 1. Top cover | |
| Thickness | 0.1 mm |
| Material | Silicone |
| Color | Red |
| Surface | Fabric with Impregnation |
| Hardness | - |
| 2. Internal layer(s) | |
| Material | Rubber |
| Color | Tan + Grey |
| 3. Bottom cover | |
| Thickness | - |
| Material | - |
| Color | Natural |
| Surface | Bare Fabric |
| Hardness | - |
| Anti-static Yarn | - |
| BELT TENSION: | |
| Tensile Strength(N/mm) | 400 |
| Max. Suggested Load(N/mm) | 23 |
| Working Load 2% Elongation(N/mm) | 25 |
| FRICTION COEFFICIENTS ON: | |
| Smooth Stainless Steel | 0.2 |
| REMARKS | |
| Max. Manufacturing Width | 1500mm |
| Standard Width | 1500mm |
| MINIMUM PULLEY DIAMETERS: | |
| Front Flexing | 100 mm |
| Back Flexing | 120 mm |
| CONVEYOR FRAME: | |
| Horizontal Rollers | Yes |
| Slider bed | Yes |
| Troughed application | Yes |
| SPECIAL CHARACTERISTICS: | |
| Food Grade | No |
| Oil Resistant | No |
| Flame Retardant | No |
| Surface Antistatic | No |
| Cold Resistant | No |
| High Temperature | Yes |
| JOINING INSTRUCTIONS: | |
| Finger Joint | Vulcanizing, Steel Fastener |
| Welding Temperature（°C） | 160 ºC ± 10 ºC |
| Pressure | 2 bar |
| Cooling | Cool Immediately |
