Water-Cooled Conveyor Belt Splice Press / Joint Machine – 600-4000mm Working Width
Water-Cooled Conveyor Belt Splice Press / Joint Machine – 600-4000mm Working Width

Water-Cooled Conveyor Belt Splice Press / Joint Machine – 600-4000mm Working Width

Water-Cooled Conveyor Belt Splice Press designed to provide efficient, high-quality splicing and jointing for conveyor belts of various widths, ranging from 600mm to 4000mm. Guarantees strong and durable joints for PVC and TPU conveyor belts.

  • Wide Working Range (600-4000mm) – Versatile enough to handle a variety of belt sizes, from small to large-scale splicing needs.
  • Water-Cooled System – Ensures precise temperature control for flawless, high-strength joints.
  • Heavy-Duty Performance – Perfect for continuous use in high-demand industrial environments.
  • Efficient & Reliable – Ensures minimal downtime with quick and effective splicing, improving productivity.
  • User-Friendly – Easy-to-use interface for efficient operation and control.

Custom colors, thicknesses, profiles and special features available upon request, please contact us for more information.

Technical Data
Model KCB-J1000 KCB-J1800
Max. Temperature 195 °C 195 °C
Working Width 1000 mm 1800 mm
Air Chamber Pressure 0-2.5 kg/cm2, adjustable 0-2.5 kg/cm2, adjustable
Voltage 220V / 380V 220V / 380V
Power 3.3 KW 5.9 KW
Dimensions (L*W*H) 1470*370*580 mm 2420*370*580 mm
Gross Weight 140 kgs 200 kgs
Model Voltage (V) Power (kW) Working Width (mm)
KCB-J600 220 / 380 1.4 600
KCB-J1000 220 / 380 3.3 1000
KCB-J1200 220 / 380 4 1200
KCB-J1600 220 / 380 5.2 1600
KCB-J1800 220 / 380 5.9 1800
KCB-J2000 220 / 380 7 2000
KCB-J3000 220 / 380 9.6 3000
KCB-J4000 220 / 380 12 4000
